New Generation N62 Engine Chapter 3 P.20
Course Contents/Background Material
© BMW AG, Service Training
Ancillary components and belt drive
- Belt drive
Fig. 17: Belt drive
Index Description Index Description
1 Air conditioning
compressor
6 Alternator
2 4-V-belt 7 Deflection pulley
3 Crankshaft
pulley
8 Power steering pump
4 Coolant pump 9 6-V-belt
5 Tensioning unit main drive 10 Tensioning unit A/C drive
KT-6968
