New Generation N62 Engine Chapter 3 P.27
Course Contents/Background Material
© BMW AG, Service Training
- Starter motor
The starter motor is located on the right-hand side of the engine
below the exhaust manifold, and is a compact planetary drive
starter with a 1.8 kW output.
Fig. 22: N62 engine
- Power steering pump
The power steering pump is a tandem radial piston pump, and is
driven by the 6-V-belt. A vane pump is fitted on cars without the
Dynamic-Drive-System.
Further information about the power steering pump can be
found in the Chassis/steering section.
Index Description
1 Starter motor with heat-protective cover
KT-7682
