New Generation N62 Engine Chapter 3 P.35
Course Contents/Background Material
© BMW AG, Service Training
Camshafts
Fig. 29: Camshafts
The camshafts are made from chilled cast iron and are hollowed
to reduce their weight. The camshafts are fitted with balancing
weights for equalising imbalances in the valve gear.
Index Description
1 Camshaft sensor wheels
2 Thrust bearing area with oil ducts for the VANOS units
KT-7683
