New Generation N62 Engine Chapter 3 P.62
Course Contents/Background Material
© BMW AG, Service Training
Fig. 46: Coolant flow to the rear of the engine block
From the rear of the engine block, the coolant flows through the
side apertures to the cylinder walls, and from there it flows to the
cylinder heads.
Fig. 47: Cast aluminium cover at the rear of the engine block
KT-7725
KT-7695
