Machine description – quick overview
Smootharc Elite MIG 451 Progress Pulse
099-004839-BOC01
10.11.2009
17
Item Symbol Description 0
1
Lifting lug
2
Signal light, Ready
3
Main switch, machine on/off
4
Carrying handle
5
Connection socket, “+” welding current
6
Connection socket, “-” welding current
7
Coolant tank cap
8
Coolant tank
9
Automatic cut-out of coolant pump key button
press to reset a triggered fuse
10
Cooling air inlet
11
Conveyor rolls, guide castors
