BOC Smootharc Elite MIG 451 Progress Pulse - Resetting Jobs (Welding Tasks) to the Factory Settings; Resetting a Single JOB; Resetting All Jobs

Rectifying faults
Resetting JOBs (welding tasks) to the factory settings
099-004839-BOC01
10.11.2009
37
7.3 Resetting JOBs (welding tasks) to the factory settings
NOTE
All customised welding parameters that are stored will be replaced by the factory
settings.
7.3.1 Resetting a single JOB
JOB-
LIST
JOB-
LIST
m/min
Figure 7-1
Display Setting/selection
Reset to factory settings
The RESET will be done after pressing the button.
The menu will be ended when no changes are done after 3 sec.
JOB-number (example)
The shown JOB will be set to ex works.
7.3.2 Resetting all JOBs
m/mi
n
JOB-
LIST
JOB-
LIST
Figure 7-2
Display Setting/selection
Reset to factory settings
The RESET will be done after pressing the button.
The menu will be ended when no changes are done after 3 sec.
