BOC Smootharc Elite MIG 451 Progress Pulse - Connection for Workpiece Lead

Design and function
TIG welding
28
099-004839-BOC01
10.11.2009
5.9.2 Connection for workpiece lead
1
Figure 5-6
Item Symbol Description 0
Connection socket, "+" welding current
1
• TIG welding: Workpiece connection
• Insert the cable plug on the work piece lead into the "+" welding current connection socket and lock by
turning to the right.
