Bodet Style 5 User Manual

13
III – Connecting to the time distribution network
Connect the 100-240VAC 50/60Hz mains power supply. (See chapter 2.)
3.1 Parallel distribution with inverted polarity
Minute // (12-24-48 Volt), ½ minute // (24 Volt) and AFNOR
1) Ensure that the clock is designed to be synchronised by "Impulse" or to be connected to a time
code distribution network that meets the AFNOR standard .
2) Connect the impulse cable to terminal strip (A). Use the correct polarity for impulse synchronisation.
There is no polarity in AFNOR.
Minute or ½ minute mode (only)
3) Select the impulse transmission frequency (minute or ½ minute) and display mode
(refer to the page 29).
4) Set the clock to the correct time (refer to page 15).
IV – Default configuration
To restore factory settings, press the red button on the electronic board until the clock turns black.
Open the clock to access this button (see Installation).
Location of button on the electronic board (example shows an Impulse card):
EN
A
IMPULSE
AFNOR
OR
A
