STEP
10.0
49
Be careful to assemble all components
in the sequence they are presented.
Long Cable (D24)
Stamped Eye End
24’ 8 3/4”7540 mm
Ball Stop End
22
33
99
44
55
77
66
11
88
Use the lower half of
this oating pulley
d20
d38
a12
d20
Z
Small Straight
Bar
d24
Long Cable
88
