Allgemeines.pm6.5 - USA
Page 1.8
General
BOGE Operating instructions for S 40-2...S 341 / SF 40-2...SF 220 series screw compressors
Data
on the type plate
1. 2 Introduction
BOGE does not accept any liability for breakage or transportation damage.
Please inspect the compressor immediately after delivery and direct dam-
age claims to the last carrier even when the packing is not damaged!
To safeguard claims against the carrier we recommend leaving the machine,
devices and packing material in the same condition as they were in when
the damage was detected.
In the event of any other complaints, please inform us within six days after
arrival of the delivery.
Enter the data of your compressor from the type plate or enclosed data
sheet in the illustration below. This will ensure that in the event of enquiries,
you will always have the most important data at hand.
Transportation
damage
Please do not hesitate to contact BOGE service if you have any questions.
Please call:
770 -874-1570
In the event of inquiries, always specify the following data of your compressor
to prevent any delays:
Type
Year of manufacture
Machine number
NOTICE!
Only BOGE service technicians or persons authorized by BOGE in writing
may repair or alter the compressor during the warranty period. Otherwise all
warranty claims will expire!
Service
Fig. 1.1: Data on the type plate
