Aufstellung.pm6.5 - USA
Page 3.2
Installation
BOGE Operating instructions for S 40-2...S 341 / SF 40-2...SF 220 series screw compressors
Installation surface
Fire protection
3.2 Compressor room
A level industrial floor without foundation is adequate for the installation of the
compressor. No special fastening elements are required.
WARNING!
Requirements of fire protected compressor rooms:
Flammable liquids must never be stored in the compressor room.
The floor around the compressor must be made of non-flammable material.
Leaking oil must not spread out over the floor.
No inflammable materials must be located within a radius of at least
3 metres around the compressor.
No inflammable machine parts, such as cable ducts, may run overhead
of the compressor.
The compressor room must be clean, dry, cool and free of dust.
Admissible ambient temperatures (see "Technical data")
Maximum ambient temperature (for air cooling): + 104 / 113°F
Minimum ambient temperature: +
141°F
CAUTION!
Nonobservance of the admissible ambient temperature may lead to the
following problems:
The compressor will switch off when the admissible final compres-
sion temperature is exceeded or gone below.
Pipe lines and valves will freeze up at low temperatures.
Damage due to reduced lubricating ability of the compressor oil.
Measures to be taken to ensure that admissible ambient temperatures
are observed:
Avoid any pipe lines or units radiating heat in the vicinity of the compres-
sor, or insulate them well.
Never install the compressor in the cooling air flow of other machines.
Provide the supply air openings with adjustable louvres to ensure that
the minimum temperature is not gone below in winter.
Use the BOGE frost protection device.
The compressor must be installed frost-protected.
If the following instructions are not observed, the admissible final
compression temperature may be exceeded.
In this case, the compressor will switch off automatically.
CAUTION!
Arrange the compressor intake openings or ducts such, that dangerous
admixtures (e.g. explosive or chemically unstable materials) cannot be
drawn in.
Frost protection
Admissible
environmental
influences
Ventilation
