Page #40 background imageLoading...
Page #40 background image
Aufstellung.pm6.5 - USA
Page 3.10
Installation
BOGE Operating instructions for S 40-2...S 341 / SF 40-2...SF 220 series screw compressors
CAUTION!
Always check the rotational direction of the drive motor prior to commission-
ing/initial start up.
Even brief operation in the wrong direction of rotation (more than approx.
5 seconds) may cause total destruction of the air end!
Ensure that the rotational direction coincides with the rotational direction
arrow on the air end.
Switch on the main switch.
Switch the compressor on and immediately off again to check the rota-
tional direction.
Changing the rotational direction:
DANGER: Risk of injury!
Switch off the main switch and secure against unintentional switching-on.
Interchange two phases (L1, L2 or L3) in the power cable.
Open ball valve on the compressor outlet.
Undertake the following to prevent leaks:
Check screw connection of the lines and retighten, if necessary.
Check to ensure that the oil filter and oil separator are hand tight seated.
Switch on the main switch.
Switch on the compressor using the ON key. The compressor starts.
The compressor switches off automatically once the switch-off pressure,
factory set on the operating pressure switch, has been reached.
Check the supply pressure on the supply pressure gauge.
If necessary, reset operating pressure switch.
The compressor is ready for operation.
Checking the rotational
direction
Opening the stop valves
3.5 Commissioning
Checking for leaks
Conduct trail run
