11
RIVKLE
®
P1007 - Lightweight tool for speed and accessibility
Technical characteristics / Data
Advantages:
Ultra-lightweight and compact
Suitable for small diameter RIVKLE
®
nuts and studs
Precision of the setting force
M14M12M10M8M6M5M4M3
Ø RIVKLE
®
Material
Steel
Stainless steel
Aluminium
Maximum stroke
Maximum setting force
Operating air pressure
Weight without tooling
Air consumption
Noise level
7.0 mm
13 kN
5,5 bar min to 7 max
1,8 kg
8 L max per cycle
< 70 dB (A)
Production rate
32 RIVKLE
®
/min
236 15 700 301 236 15 701 001
2 - 3 Kg
282 59 010 820
2,2 - 4 Kg
282 59 010 665
2,2 - 4 Kg
282 59 010 664
KIT
For tooling, please refer to page 22
RIVKLE
®
P1007
236 15 701 000
Generic code for a tool with preset force cartridge: 282 52 000 005
It is also possible to get preset cartridge separately. See page 20.
RIVKLE
®
P1007 - Special accessories
