9
RIVKLE
®
– Stroke controlled installation equipment
Setting stroke adjustment
RIVKLE
®
P2005 - The stroke setting power hand tool
Technical characteristics / Data
RIVKLE
®
P2005 - Special accessories
Advantages:
Robust
Fast
M14M12M10M8M6M5M4M3
Ø RIVKLE
®
Steel
Stainless steel
Aluminium
Maximum stroke
Maximum setting force
Operating air pressure
Weight without tooling
Air consumption
Noise level
7,0 mm
26 kN with 6,5 bar input
5,5 bar min to 7 max
2,6 kg
8 L max per cycle
< 70 dB (A)
Production rate
35 RIVKLE
®
/min
236 15 500 305 236 15 501 001
RIVKLE
®
P2005
2 - 3 Kg
282 59 010 820
2,2 - 4 Kg
282 59 010 665
2,2 - 4 Kg
282 59 010 664
KIT
For tooling, please refer to page 22
Material
236 15 501 000
Stroke controlled hand setting tool, based on hydro-pneumatic technology. Only need to be connected to an air source.
The air energy is transformed into hydraulic pressure, which drives the setting operation to the preset stroke.
RK HANDTOOLS EN:Mise en page 1 25/11/19 13:33 Page 9
