8
RIVKLE
®
– How to ensure that a RIVKLE
®
is correctly set?
Principle
RIVKLE
®
is mainly used in blind conditions, so the most reliable way to ensure that
a RIVKLE
®
has been set correctly is to ensure that the setting parameters are strictly
enforced.
A RIVKLE
®
correctly set means that it meets all it's mechanical characteristics.
Controlling the force setting method (RIVKLE
®
P1007, P2007, B2007, P3007, EPX009)
Idea is to ensure that the tool has given, and still gives the correct force to the RIVKLE
®
. Each tool gets it proper force
adjustment but the most reliable way to control it is to use a RIVKLE
®
FC340 force controller, as described page 20.
If your tool is dedicated to an unique RIVKLE
®
, you can fix its force using either a preset cartridge set to a given
force value (RIVKLE
®
PX007), either locking adjustment in the menu (RIVKLE
®
B2007), which makes it impossible
to adjust.
Controlling the stroke setting method (RIVKLE
®
P2005)
Idea is to ensure that the stroke which is applied on RIVKLE
®
is correct. By controlling L2 value (only for RIVKLE
®
with both side access) or by controlling stroke on the tool before setting (S value). Thickness of the application has
to be consistant.
Example:
It is best is to test a setting on a sample plate with the same thickness as the application and compare the measurement
of the RIVKLE
®
lenght, before and after crimping - L – L2 = S
e = thickness of parent
material in mm
<
>
S
<
>
L2
+0,1
/
0
(mm)
L
2
(mm)
E max
(mm)
S
(mm)
d
(mm)
L
(mm)
B
(mm)
<
<
<
<
<
<
e
(min - max)
(mm)
> <
> <
H
>
<
>
<
M3
6,0 0,65
1,5 - 2,5
343 41 030 025
10,25 5,0
S=3,5-e
6,0
M4
0,5 - 3,0
343 41 040 030
10,8
6,5
6,0
S=4,5-e
6,2
0,3
3,0 - 5,5
343 41 040 055
13,5 S=7,0-e
M5
0,5 - 3,0
0,5 - 3,5
343 41 050 030
343 41 050 055
14,0
9,0
7,0
S=4,5-e
9,2
3,0 - 5,5
16,5
S=7,2-e 9,0
0,4
0,4
M6
343 41 060 030
16,0
11,1
9,0
S=5,5-e
10,2
3,5 - 6,0
343 41 060 060
19,0 S=8,5-e
M8
0,7 - 3,5
343 41 080 030
18,0
13,4
11,0
S=5,2-e
12,5 0,5
3,5 - 6,0
343 41 080 060
21,0
S=8,2-e
M10
1,0 - 3,5
343 41 100 035
22,0
16,0
13,0
S=6,0-e
16,0
0,5
3,0 - 6,0
343 41 100 060
25,0
S=8,6-e
M12
1,0 - 4,0
343 41 120 040
24,8
18,8
16,0
S=7,8-e
1,0
RIVKLE
®
Plus
Steel | Thin head | Hexagonal | Open
RK HANDTOOLS EN:Mise en page 1 25/11/19 13:33 Page 8
