BONAIRE 5000D - Page 14

INSTALLATION INSTRUCTIONS
14
Unit Installation
e. Disconnect the motor and pump cables from control box plugs.
f. Slide the lid out (be careful as the electrical box is attached to the underside of the lid)
of the grill assemblies. Leave the side discharge panel in place.
g. Remove the tape fastening the fan assembly to the base. Carefully lift the fan from
the down discharge position.
Disconnect
plugs
