connections by hand only.
Make sur
e it is fastened securely and tighten
by turning the regulator coupling nut clockwise.
regulator from the table top (B) to the cylinder valve
close the propane tank. Attach the preassembled
Turn the cylinder valve on the tank clockwise to
1-866-771-2663 | Page 9
7. Place propane gas tank (not included) into the
metal stand (J). Make sure the gas tank sits on the
metal stand (J) completely. Turn the preassembled
wing screw on the outer part of metal stand (J)
clockwise to secure the propane gas tank tightly.
CYLINDER V
ALVE
PRESSURE
RELIEF VALVE
BLEED-OFF
VALVE
BLACK COUPLING NUT
REGULATOR
turn clockwise to connect
turn clockwise
to reseal
8.
K
O
9. Pour the box of lava rocks (K) into the frebowl
(O).
T
o ensure proper function, the guard (N) on this
burner (P) should be free of lava rocks at all times.
CAUTION
N
P
To Next Page
