29
Polyalphaolefin synthetic oils (PAO)
Brake lubrication
The hydraulic multi-disk brakes are lubricated with the same oil as the gear unit.
Only synthetic lubricants may be used on gear units conforming to European Directive
94/9/EC. Refer to the above chart for the brand and type.
Plug thread Pitch Tightening torque
[Nm]
M14 1,5 15 - 20
M16 1,5 15 - 20
M18 1,5 15 - 20
M20 1,5 20 - 30
M22 1,5 20 - 30
M24 1,5 20 - 30
M30 2 30 - 40
M42 3 40 - 50
Plug thread Pitch Tightening torque
[Nm]
1/8" 28 10 - 15
1/4" 19 10 - 15
3/8" 19 15 - 20
1/2" 14 20 - 30
3/4" 14 20 - 30
1" 11 30 - 40
5.5 - LUBRICATION
Before starting up the gear unit, it must be charged with lubricant to the level corresponding to its specified
mounting position.
The lubricant and its relative viscosity should be selected from the following chart, in accordance with the
type of duty and ambient temperature.
If the gear unit is supplied ready charged with lubricant, replace the closed shipping plug with the
vent plug included in the shipment before installing it.
(A1)
(A2)
INDUSTRIAL PLANTS MOBILE MACHINES
ISO standard .. EP grade SAE standard .. API GL5 grade
T
a
-10°C / +30°C +10°C / +45°C -20°C / +60°C -20°C / +30°C +10°C / +45°C
ISO VG 150 ISO VG 220 ISO VG 150-220 SAE 80W/90 SAE 85W/140
AGIP BLASIA150 BLASIA 220 BLASIA SX 220 ROTRA MP ROTRA MP
ARAL DEGOL BG 150 DEGOL BG 220 DEGOL PAS 150-220 GETRIEBEOL HYP GETRIEBEOL HYP
BP ENERGOL GR XP 150 ENERGOL GR XP 220 EVERSYN EXP 150-220 HYPOGEAR EP HYPOGEAR EP
CASTROL ALPHA SP 150 ALPHA SP 220 ALPHASYN EP 150-220 HYPOY HYPOY
CEPSA ENGRANAJES HP 150 ENGRANAJES HP 220
ENGRANAJES HPX
150-220
TRANSMISIONES EP TRANSMISIONES EP
CHEVRON
N.L. GEAR COMPOUNDS
EP 150
N.L. GEAR COMPOUNDS
EP 220
TEGRA SYNTHETIC
GEAR EP 150-220
RPM UNIVERSAL GEAR
LUBRICANTS
RPM UNIVERSAL GEAR
LUBRICANTS
ESSO SPARTAN EP 150 SPARTAN EP 220 SPARTAN S EP 150-220
GEAR OIL GX GEAR OIL GX
PONTONIC MP PONTONIC MP
FUCHS RENOLIN CKC 150 RENOLIN CKC 220
RENOLIN UNISYN
CKC 150-220
TITAN SUPER GEAR TITAN SUPER GEAR
KLUBER KLUBEROIL GEM1-150 KLUBEROIL GEM1-220
KLUBERSYNT
EG 4-150 / 4-220
Q8 GOYA 150 GOYA 220 EL GRECO 220
MOBIL MOBILGEAR 600 XP 150 MOBILGEAR 600 XP 220
MOBILGEAR
SHC XMP 150-220
MOBILUBE HD MOBILUBE HD
MOLYCOTE L-0115 L-0122 L-2115 / L-2122
REPSOL SUPER TAURO 150 SUPER TAURO 220
SUPER TAURO
SINTETICO 150-220
SHELL OMALA EP150 OMALA EP220 TIVELA OIL S SPIRAXHD SPIRAX HD
TOTAL CARTER EP 1500 CARTER EP 2200 CARTER SH 150-220 TRANSMISSION TM TRANSMISSION RS
