6 Parameter list
The parameter list is structured according to the menu branches of the operating unit.
For better clarity, the parameters have been marked with pictograms:
The parameter is available in the four data sets
The parameter value is set by the SET-UP routine
This parameter cannot be written in the operation of the frequency inverter.
6.1 Actual value menu (VAL)
Actual values of the system
No. Description Unit Display range Chapter
242 Load % 0.0 ... 999.9 5.1
243 Estimated load % 0.0 ... 999.9 5.1
6.2 Parameter menu (PARA)
Temperature adjustment
No. Description Unit Display range Chapter
465 Operation mode - Selection 5.4
467 Adjusting temperature °C -50.0 ... 300.0 5.4
Speed controller
769 Frequency Upper Limit Source - Selection 5.3
Brake control
800 Time t1 s 0.0 ... 20.0 4.2
801 Time t2 s 0.0 ... 20.0 4.2
802 Time t3 s 0.0 ... 20.0 4.2
803 Time t4 s 0.0 ... 20.0 4.2
804 Time t11 s 0.0 ... 20.0 4.2
805 Time t12 s 0.0 ... 20.0 4.2
806 Time t13 s 0.0 ... 20.0 4.2
807 Time t15 s 0.0 ... 20.0 4.2
808
Monitoring current
A
0.0 ... o⋅I
FIN
4.2.1
809 Frequency threshold % 0.0 ... 100.0 4.2.2
Load estimation
811 Mech. time constant s 0.000 ... 65.000 5.1.1
812 Turn/m U/m 0.01 ... 650.00 5.1.2
813 Fm lower value LE % 0 ... 100 5.1.3
815 Max time LE s 0.001 ... 65.000 5.1.3
816Pull-out torque at Fmax % 0 ... 100 5.1.3
817Speed switch-off Limit Hz 0.00 ... 999.99 5.1.3
818
I limit A
0.01⋅I
FIN
... 3⋅o⋅I
FIN
5.1.3
819
Desired Isq up A
0.01⋅I
FIN
... o⋅I
FIN
5.2.1
820 Desired Isq down at FsR A
0.01⋅I
FIN
... o⋅I
FIN
5.2.1
821 Desired Isq down at Fmax A
0.01⋅I
FIN
... o⋅I
FIN
5.2.1
822 Operation mode LE - Selection 5.1
