Display actual values
Parameter Display
R.m.s Current [A] P211 R.m.s output current of the frequency
inverter (motor current).
Output Voltage [V] P212 Output voltage of the frequency inverter.
Active Power [kW] P213 Power of the motor at the current operation
point.
Actual Speed [min
-1
] P240 Motorspeed.
Actual frequency [Hz] P241 Output frequency of the inverter (actual
frequency of the motor).
Current Error P259 The cause of of error switch-off.
Warnings P269 Warning because of a critical condition.
Last Error P310 The last error.
Optional communication modules
RS485, Modbus oder VABus: CM-485
RS232, Modbus oder VABus: CM-232
Profibus-DP: CM-PDPV1
CANopen
VABus/TCP:
CM-CAN
CM-VABus/TCP
CM-VABus/TCP-2P
EtherCAT: CM-EtherCAT
®
ProfiNet: CM-ProfiNet
Modbus/TCP: CM-Modbus/TCP
CM-Modbus/TCP-2P
EtherNet/IP: CM-EtherNet/IP
CM-EtherNet/IP-2P
Communication interface X21 with RJ45 connection
For serial RS485 communication via VA Bus or Modbus protocol.
BONFIGLIOLI Vectron provides an interface adaptor for the USB connection of a PC.
This enables parametrization and monitoring via the PC software VPlus.
Parameter copy
Parameter values can be stored on a memory card („Ressource Pack“) and transferred from
one inverter to another inverter.
Reset to factory setting
Select P34 in menu item PARA. Press the arrow keys at the same time, to jump to the value
4443. Set P34 to 4444 and press ENT. This resets the parameter settings to the default
values.
Key lock
Select P27 in menu item PArA and set a password. Then parameter values in menu item PArA
and the motorpoti function are password protected. Ten minutes after a correct password
entry the password inquiry is displayed again.
Further information
Detailled operating instructions can be downloaded from the website of BONFIGLIOLI.
