Voorhout • Groningen • Weert • Hoogerheide T +31(0)88 7865800 I elsto.eu
05/2013 49 Quick Start Guide
Agile
AGL402 (3.0 … 11.0 kW, 400 V)
Type
400 V, 3-phase
Agile
402 -15 -18 -19 -19 -21 -22 -23
Size 2 3
Output motor side
Recommended motor shaft
power
P kW 3.0 4.0 5.5 5.5 7.5 9.2 11.0
Output current I A 7.5 9.5 12.0 13.0 17.0 20.0 23.0
Long-term overload
current (60 s)
I A 11.2 14.2 18.0 19.5 25.5 30.0 34.5
Short-time overload
current (1 s)
I A 15.0 19.0 24.0 26.0 34.0 40.0 43.0
Switching frequency f kHz 2, 4, 8, 16
Output, brake resistor
Minimum brake resistor R Ω 106 106 106 48 48 48 48
Recommended brake resistor
(770 V)
R Ω 148 106 106 80 58 48 48
Input mains side
Rated current I A 6.8 7.8 13.8 14.2 15.8 20.0 26.0
Maximum mains current
1)
I A 9.8 12.8 17.2 17.2 23.0 28.1 33.6
Fuses I A 10 10 16 16 25 25 35
Fuses UL type I A
Bussmann
FWP-20A14Fa
Bussmann
FWP-30A14Fa
Mechanics
Dimensions
2)
HxWxD mm 200 x 80 x 196 200 x 125 x 205
Weight (approx.) m kg 1.5 3
Degree of protection - - IP20 (EN60529)
Terminals A mm
2
Mains and motor
terminals:
0.2 … 4 (flexible with
sleeve)
0.2 … 6 (rigid)
Terminals relay output: 0.1 … 1.5
Installation -- vertical
Interior fan - - yes
Heat sink fan - - yes
Ambient conditions
Power dissipation (2 kHz switch-
ing frequency)
P W 133 167 230 235 321 393 470
1) According to DIN EN 61800-5-1.
2) Dimensions of the basic device.
