Device data
General are valid for AGL202 and AGL402 devices are the following characteristics:
Output motor side
Output voltage U V Maximum value of input voltage, three-phase
Protection - - Short circuit proof and earth fault proof
Rotary field frequency f Hz 0 ... 1000, depending on switching frequency
Integrated brake chopper - - yes
Input mains side
Mains configuration -- TT, TN, IT
Mains voltage range
(EN61800-5-1)
UV
AGL202: 230 (-20 %) … 240 (+10 %)
AGL402: 380 (-15%) … 480 (+10%)
Mains frequency f Hz 45 ... 69
Overvoltage category - - EN 50178 III, EN 61800-5-1 III
Ambient conditions
Cooling agent temperature (air) T
n
°C
0 ... 40 (EN 60721-3-3),
40 … 55 with power reduction (derating)
Storage temperature T
°C -25 ... 55
Transport temperature T
T
°C -25 ... 70
Relative air humidity -%
Operation: max. 85
non-condensing
Storage: 5 …95
GL202 devices in the sizes 1 to 3 can be operated either with sin
le phase or three
phase connection. In sin
le phase operation a lower power compared to three phase
operation is available. The type codes correlate to the three phase power.
