Quick Start Guide
Agile
44 05/2013
AGL202 (3~:0.18 … 0.55 kW, 1~:0.09 … 0.25 kW, 230 V)
Type
230 V
Agile
202
-01 -02 -03 -05
Size 1
Output motor side
Selected Mains supply 1ph 3ph 1ph 3ph 1ph 3ph 1ph 3ph
Recommended
motor shaft power
P kW
0.09 0.18 0.12 0.25 0.18 0.37 0.25 0.55
Output current I A 0.8 1.3 1.0 1.5 1.3 2.0 1.5 3.0
Long-term
overload current (60 s)
I A
1.2 2 1.5 2.25 1.95 3.0 2.25 4.5
Short-time
overload current (1 s)
I A
1.6 2.6 2.0 3 2.6 4.0 3.0 6.0
Switching frequency f kHz 2, 4, 8, 16
Output, brake resistor
Minimum brake resistor R Ω 100 100 100 100 100 100 100 100
Recommended brake resis-
tor (385 V)
R Ω
300 220 250 200 220 140 200 100
Input mains side
Rated current I A 1.7 1.2 1.9 1.4 2.5 2.0 3.0 2.5
Maximum mains current
1)
I A 2.5 2.2 2.9 2.5 3.6 3.3 4.2 4.0
Fuses I A 6 6 6 6 6 6 6 6
Fuses UL type I A Bussmann FWP-10A14Fa
Mechanics
Dimensions
2)
HxWxD mm 200 x 60 x 170
Weight (approx.) m kg 1.1
Degree of protection - - IP20 (EN60529)
Terminals A
mm
2
Mains and motor
terminals:
0.2 … 4 (flexible with sleeve)
0.2 … 6 (rigid )
Terminals relay
output:
0.1 … 1.5
Installation - - vertical
Interior fan - - no
Heat sink fan - - no
Ambient conditions
Power dissipation (2 kHz
switching frequency)
P W
12 12 19 19 29 29 42 42
1) According to DIN EN 61800-5-1.
2) Dimensions of the basic device.
