05/2013 45 Quick Start Guide
Agile
AGL202 (3~:0.75 … 2.2 kW, 1~:0.37 … 1.1 kW, 230 V)
Type
230 V
Agile
202 -07 -09 -11 -13
Size 1
Output motor side
Selected Mains supply 1ph 3ph 1ph 3ph 1ph 3ph 1ph 3ph
Recommended
motor shaft power
P kW
0.37 0.75 0.55 1.1 0.75 1.5 1.1 2.2
Output current I A 2.0 3.5 3.0 5.0 3.5 6.0 5.0 9.0
Long-term
overload current (60 s)
I A
3.0 5.25 4.5 7.5 5.25 9.0 7.5 13.5
Short-time
overload current (1 s)
I A
4.0 7.0 6.0 10 7.0 12.0 10.0 18.0
Switching frequency f kHz 2, 4, 8, 16
Output, brake resistor
Minimum brake resistor R Ω 100 100 100 100 37 37 37 37
Recommended brake resistor (385 V) R Ω 100 100 100 100 92 63 70 41
Input mains side
Rated current I A 4.2 3.4 5.3 4.9 7.6 6.5 11.2 9.5
Maximum mains current
1)
I A 5.5 5.1 6.9 6.7 11.4 10.8 15.5 14.5
Fuses I A 6 6 6 6 10 10 16 16
Fuses UL type I A Bussmann FWP-10A14Fa
Mechanics
Dimensions
2)
HxWxD mm 200 x 60 x 170
Weight (approx.) m kg 1.1
Degree of protection - - IP20 (EN60529)
Terminals A mm
2
Mains and
motor
terminals:
0.2 … 4 (flexible with
sleeve)
0.2 … 6 (rigid)
Terminals
relay out-
put:
0.1 … 1.5
Installation - - vertical
Interior fan - - no
Heat sink fan - - yes
Ambient conditions
Power dissipation (2 kHz switching
frequency)
P W
53 53 70 70 89 89 122 122
1) According to DIN EN 61800-5-1.
2) Dimensions of the basic device.
