Quick Start Guide
Agile 46 05/2013
AGL202 (3~:3.0 … 4.0 kW, 1~:1.5 … 2.2 kW, 230 V)
Type
230 V
Agile 202 -15 -18
Size 2
Output motor side
Selected Mains supply 1ph 3ph 1ph 3ph
Recommended
motor shaft power
P kW
1.5 3.0 2.2 4.0
Output current I A 6.0 12.0 9.0 15.0
Long-term
overload current (60 s)
I A
9.0 18.0 13.5 22.5
Short-time
overload current (1 s)
I A
12.0 24.0 18.0 30.0
Switching frequency f kHz 2, 4, 8, 16
Output, brake resistor
Minimum brake resistor R Ω 18.5 18.5 18.5 18.5
Recommended brake resis-
tor (385 V)
R Ω
72 37 41 27
Input mains side
Rated current I A 14.2 12.5 19.5 17.0
Maximum mains current
1)
I A 20.6 18.5 28.0 25.5
Fuses I A 16 16 25 25
Fuses UL type I A Bussmann FWP-20A14Fa
Mechanics
Dimensions
2)
HxWxD mm 200 x 80 x 196
Weight (approx.) m kg 1,5
Degree of protection - - IP20 (EN60529)
Terminals A mm
2
Mains and motor
terminals:
0.2 … 4 (flexible with sleeve)
0.2 … 6 (rigid)
Terminals relay
output:
0.1 … 1.5
Installation - - vertical
Interior fan - - yes
Heat sink fan - - yes
Ambient conditions
Power dissipation (2 kHz
switching frequency)
P W
133 133 167 167
1) According to DIN EN 61800-5-1.
2) Dimensions of the basic device.
