05/2013 47 Quick Start Guide
Agile
AGL202 (3~:5.5 … 7.5 kW, 1~:3.0 kW, 230 V)
Type
230 V
Agile
202 -19 -21
Size 3
Output motor side
Selected Mains supply 1ph 3ph 1ph 3ph
Recommended
motor shaft power
P kW
3.0 5.5 3.0 7.5
Output current I A 12.0 21.0 12.0 26.0
Long-term
overload current (60 s)
I A
18.0 31.5 18.0 39.0
Short-time
overload current (1 s)
I A
24.0 42.0 24.0 44.0
Switching frequency f kHz 2, 4, 8, 16
Output, brake resistor
Minimum brake resistor R Ω 18.5 18.5 18.5 18.5
Recommended brake resistor
(385 V)
R Ω
32 19 32 18.5
Input mains side
Rated current I A 26.7 22.5 26.7 30.0
Maximum mains current
1)
I A 40.0 33.0 40.0 41.5
Fuses I A 35 35 35 35
Fuses UL type I A Bussmann FWP-30A14Fa
Mechanics
Dimensions
2)
HxWxD mm 200 x 125 x 205
Weight (approx.) m kg 3
Degree of protection - - IP20 (EN60529)
Terminals A mm
2
Mains and
motor termi-
nals:
0.2 … 4 (flexible with sleeve)
0.2 … 6 (rigid)
Terminals relay
output:
0.1 … 1.5
Installation -- vertical
Interior fan - - yes
Heat sink fan - - yes
Ambient conditions
Power dissipation (2 kHz
switching frequency)
P W
235 235 235 321
1) According to DIN EN 61800-5-1.
2) Dimensions of the basic device.
