Quick Start Guide
Agile
48 05/2013
AGL402 (0.25 … 2.2 kW, 400 V)
Type
400 V, 3-phase
Agile
402 -02 -03 -05 -07 -09 -11 -13
Size 1
Output motor side
Recommended
motor shaft power
P kW 0.25 0.37 0.55 0.75 1.1 1.5 2.2
Output current I A 0.8 1.2 1.5 2.1 3.0 4.0 5.5
Long-term
overload current (60 s)
I A 1.2 1.8 2.25 3.15 4.5 6.0 8.2
Short-time
overload current (1 s)
I A 1.6 2.4 3.0 4.2 6.0 8.0 11.0
Switching frequency f kHz 2, 4, 8, 16
Output, brake resistor
Minimum brake resistor R Ω 300 300 300 300 300 220 220
Recommended brake resistor
(770V)
R Ω 2432 1594 930 634 462 300 220
Input mains side
Rated current I A 0.8 1.2 1.8 2.4 2.8 3.3 5.8
Maximum mains current
1)
I A 1.1 1.5 2.0 2.7 3.9 5.2 7.3
Fuses I A 6 6 6 6 6 6 10
Fuses UL type I A Bussmann FWP-10A14Fa
Mechanics
Dimensions
2)
HxWxD mm 200 x 60 x 170
Weight (approx.) m kg 1.1
Degree of protection - - IP20 (EN60529)
Terminals A mm
2
Mains and motor ter-
minals:
0.2 … (flexible with
sleeve)
0.2 … 6 (rigid)
Terminals relay output: 0.1 … 1.5
Installation -- vertical
Interior fan - - no
Heat sink fan - - no Yes
Ambient conditions
Power dissipation (2 kHz switch-
ing frequency)
P W 19 29 42 53 70 89 122
1) According to DIN EN 61800-5-1.
2) Dimensions of the basic device.
