BONFIGLIOLI agl 402 User Manual

Voorhout • Groningen • Weert • Hoogerheide T +31(0)88 7865800 I elsto.eu
Quick Start Guide
Agile 34 05/2013
3~400 V
Type -02…-11 -13 -15 -18 -19 -21 -22 -23
kW 0.25…1.5 2.2 3.0 4,0 5,5 7,5 9,2 11
F1 A 6 10 10 10 16 25 35 35
U,V,W
mm
2
1.5 2.5 4
PE
mm
2
2 x 1.5 2 x 2.5 2 x 4
or 1 x 10 1 x 10 1 x 10
3~230 V
Type -01…-07 -09 -11…-13 -15 -18 -19 -21
kW 0.18…0.75 1.1 1.5…2.2 3.0 4.0 5.5 7.5
F1 A 6 10 16 25 35 35 50
U,V,W
mm
2
1.5 4
PE
mm
2
2 x 1.5 2 x 4
or 1 x 10 1 x 10
1~230 V
Type -01…-07 -09 -11…-13 -15 -18 -19 -21
kW 0.09…0.37 0.55 0.75…1.1 1.5 2.2 3.0 3.0
F1 A 6 10 16 25 35 35 35
U,V,W
mm
2
1.5
PE
mm
2
2 x 1.5
or 1 x 10
Max. motor cable length [m]
Type Agile 202 Agile 402
Unshielded
cable
Unshielded
cable
Mains connection 1ph. 3ph. 3ph.
Power kW kW kW
-01 0.09 0.18 --
50 m 25 m
-02 0.12 0.25 0.25
-03 0.18 0.37 0.37
-05 0.25 0.55 0.55
-07 0.37 0.75 0.75
-09 0.55 1.1 1.1
-11 0.75 1.5 1.5
-13 1.1 2.2 2.2
-15 1.5 3.0 3.0
100 m 50 m
-18 2.2 4.0 4.0
-19 3.0 5.5 5.5
-21 3.0 7.5 7.5
-22 -- -- 9.2
-23 -- -- 11
