EN
11
Technical data
www.bora.com
Device dimensions CKFI
327
48,5
230
27,5
230 230
515
Fig. 3.5 CKFI device dimensions top view
58
13,5
300
Fig. 3.6 CKFI device dimensions front view
12
491
Fig. 3.7 CKFI device dimensions side view
3.2 CKFI
Parameter Value
Supply voltage 220 - 240 V
Frequency 50/60 Hz
Power consumption 3.68 kW
Fuse protection 1 x 16 A
Dimensions
(width x depth x height)
327 x 515 x 58 mm
Weight
(incl. accessories/packaging)
7.9 kg
Cooktop
Power levels 1 - 9, P
Warming levels 3
Front cooking zone (zone 1)
power setting
230 x 230 mm 2100 W
3680 W
Rear cooking zone (zone 2)
power setting
230 x 230 mm 2100 W
3680 W
Cooktop energy consumption
Front cooking zone (zone 1) 230 x 230 mm 182.8 (Wh/kg)
Rear cooking zone (zone 2) 230 x 230 mm 181.1 (Wh/kg)
Cooking zones bridged 230 x 460 mm 207.0 (Wh/kg)
Total (average) 190.3 (Wh/kg)
Tab. 3.2 Technical data CKFI
