bora Classic Series - Installation Dimensions

EN
23
Installation
www.bora.com
max. 480
495
min. 600
min. 50
max. 340
430
219 151
min. 900
190min. 100
290
120
Fig. 4.14 Appliance installation dimensions with shallow
silencer USDF in case of a unit depth of 600 mm
min. 100
max. 580
495
min. 700
min. 50
max. 440
530
219 151
min. 900
190
290
120
Fig. 4.15 Appliance installation dimensions with shallow
silencer USDF in case of a unit depth of 700 mm
4.6 Installation dimensions
≥600
≥800
≥900
Fig. 4.12 Minimum installation dimensions with shallow silencer
USDF
≥720
≥800
≥870
Fig. 4.13 Minimum installation dimensions with round silencer
USDR50
