EN
14
Technical data
www.bora.com
Device dimensions CKCH
327
515
235 140
Fig. 3.14 CKCH device dimensions top view
300
240
43,5
13,5
75
45
Fig. 3.15 CKCH device dimensions front view
491
480
12
17,5
Fig. 3.16 CKCH device dimensions side view
3.5 CKCH
Parameter Value
Supply voltage 220 - 240 V
Frequency 50/60 Hz
Power consumption 3.68 kW
Fuse protection 1 x 16 A
Dimensions
(width x depth x height)
327 x 515 x 75 mm
Weight
(incl. accessories/packaging)
7.2 kg
Cooktop
Power levels 1-9, P, 2-ring additional
switching
Warming levels 3
Front cooking zone (zone 1)
power setting
Ø 215 mm 2100 W
3000 W
Rear cooking zone (zone 2)
2-ring connection
Ø 120 mm
Ø 180 mm
600 W
1600 W
Cooktop energy consumption
Front cooking zone (zone 1) Ø 215 mm 191.3 (Wh/kg)
Rear cooking zone (zone 2) Ø 120/180 mm 197.6 (Wh/kg)
Total (average) 194.5 (Wh/kg)
Tab. 3.5 Technical data CKCH
