5.4 LCD operation
Through the UPS status summary screen, the user is able to
discover more useful information about the UPS, such as current
status, detail various measurements, event logs, UPS own
identification, and change the parameters setting to fit the user
requirements, optimize the function of UPS.
5.4.1 The main menu
In the default UPS status summary screen, when pressing or
<1s, detailed information about alarm, the system status and
battery will be shown.
In the default UPS status summary screen, when pressing >1s,
the display will enter the main menu tree.
The main menu tree includes six branches: UPS status menu,
event log menu, measurement menu, control menu, identification
menu and setting menu.
