33
Fig. 5.2: The default LCD display
More operation details for LCD are given in chapter 5.4
5.2 Operating mode
Different graphic symbols will be displayed according to current
operating mode or status.
Table 5-3 Status Summary Screens
Status Summary Screen
Description
Fig. 5.3
Normal mode:
The UPS is operating in Normal mode from
utility power.
