8. Troubleshooting
The online series UPS is designed for durable, automatic operation
and issues alarms to alert you whenever potential operating
problems occur. Usually the alarms shown by the control panel do
not mean that the output power is affected. Instead, they are
preventive alarms intended to alert the user. Active alarms and active
notices are accompanied by an audible buzzer.
8.1 Accessing Alarms and Conditions
The control panel provides troubleshooting information from two main
menus:
UPS status menu: Access to all active alarms
Event Log menu: Access to the most recent 50 events, which
may include active and closed alarms
UPS Status Menu
From the UPS Status menu, you can access the following screens
for troubleshooting information:
Status summary screen: The status summary screen provides
information on both mode and load. When there is a critical
alarm, the status summary screen changes from its normal white
text on a blue background to dark amber text on an amber
background.
Notice or alarm screens: A separate screen appears for each
active notice or alarm. If there are no active alarms or notices,
the display reads “No Active Alarms”.
Battery status screen: The battery status screen indicates the
battery charge mode, the percent the battery is charged, and the
runtime with the present load level.
