Quick Start Guide Subject to change without prior notice 8733914716 DDC (2014/02)
Quick Start Guide
CONFIGURABLE I/O PORT ASSIGNMENTS (SW 7.03.06)
PORT INPUT PORTS
IN-1
Digital Input Enable
Humidity Sensor (0-5V output)
CO2 Sensor (0-5V output)
Static Pressure Sensor (0-5V output)
IN-2
Humidity Sensor (0-5V output)
Remote Temperature Sensor (OA or Zone)
IN-3* Leaving Water Temperature Sensor
IN-4* UPM Input
IN-5
Filter Switch
Economizer Cooling (Entering Water Temperature Sensor)
Differential Pressure Switch
Secondary Condensate Pan
Boilerless (Entering Water Temperature Sensor)
INPUT EXPANSION MODULE (IEM) COMBINATIONS**
EXPANSION PORT 1 (A) EXPANSION PORT 2 (B) EXPANSION PORT 3 (C)
Dirty Filter Switch Fan Status Switch Valve End Switch
Smoke Detector Switch Fan Status Switch Valve End Switch
Dirty Filter Switch Fan Status Switch Differential Pressure Switch
Smoke Detector Switch Fan Status Switch Dirty Filter Switch
Dirty Filter Switch Fan Status Switch Damper End Switch
Smoke Detector Switch Fan Status Switch Secondary Drain Pan
IN-6* Discharge Air Temperature
DIGITAL OUTPUTS
DO-1* Fan
DO-2* Reversing Valve
DO-3* Compressor Stage 1
DO-4* Compressor Stage 2
DO-5**
Hot Gas Re-Heat (On/Off)
Fresh Air Damper (On/Off)
Heating Stage 1 (Aux Heat)
Boilerless Control (Aux Heat)
Economizer Cooling
Condenser Water Valve
ANALOG OUTPUTS (FHP 583 only)
AO-1
Variable Frequency Drive (Blower) ABB Drive or Equivalent
Mix Air Temperature SCR
AO-2 Modulating Hot Gas Re-Heat Valve
AO-3 Modulating Outside Air Damper
* Non-congurable, factory assigned I/O parameters
** Only one of six possible combinations per application
Congurable I/O Port Assignments
