Bosch 560 DDC - Table of Contents; Contents

| 3
Quick Start Guide Subject to change without prior notice 8733914716 DDC (2014/02)
Quick Start Guide
CONTENTS
Quick Start Guide – Hardware Setup .................4
Controller Features .............................4
Getting Started ...................................5
Jumper Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
DIP Switch Settings ...............................6
Rotary Dial Settings ...............................7
Power Up .......................................7
Quick Start Guide – Software Setup ..................8
Software Conguration Tools ....................8
Handheld BACview Module Features ..............8
Virtual BACview Module Features .................9
Getting Connected ...............................10
Conguring Application Parameters using BACview ... 11
Modifying Parameter Values Using BACview .........11
Customizing Program Features Using BACview ......12
Useful Shortcuts for Tweaking Program Features
Using BACview ...............................12
Congurable I/O Port Assignments (SW 7.03.06) ......13
Wiring Diagram .................................14
Typical FHP560 Wiring Diagram ...................14
Table of Contents
