8733914716 DDC (2014/02) Subject to change without prior notice Quick Start Guide
Quick Start Guide
©Copyright 2014 Bosch, Inc All rights reserved
Quick Start Guide – Hardware Setup
Controller Features
Battery
Network
LON Connector
Rotary Switch
Jumper Bank
RNET
Connector
Universal
Inputs
IN-1 to IN-6
Local Access Port
(see page 10)
24VAC
DIP Switch
Bank
Analog
Outputs
(583 only)
Digital
Outputs
Part Number
Hardware Setup
FHP 560 Controller
