Bosch ABS M4 - Optional Accessories

12 position function switch About 50 g
4 wheel speed sensors DF11 standard About 50 g/each
ABS warning light (MIL) About 50 g
Vehicle specific wiring harness with mo‐
torsport connectors
Depends on version
Clubsport wiring harness About 1,500 g
Mounting and vibration‐damping
boards
About 80 g
Mounting board for hydraulic unit About 210 g
Optional Accessories
Data logger C 50 F 02U V01 164‐01
Data logger C 60 F 02U V00 875‐03
Display DDU 7 F 02U V01 130‐04
Communication interface MSA Box II F 02U V00 327‐02
Wheel speed signal splitters
Quad with 2 motorsport connectors F 02U V00 203‐03
Quad with 1 motorsport connector F 02U V00 335‐03
Porsche 991 with 1 motorsport connec‐
tor
F 02U V01 928‐01
Field of application
ABS for front‐wheel, rear‐wheel or four‐
wheel drive racing cars
Part numbers
ABS M4‐Package 1 (incl. wiring harness with
motorsport connectors, individual layout
depending on customer requirements,
wheel speed sensors with production‐type
connectors)
F 02UV00 289‐01
ABS M4‐Package 2 (incl. wiring harness with
motorsport connectors, individual layout
depending on customer requirements,
wheel speed sensors with motorsport con‐
nectors)
F02U V00 290‐01
ABS M4‐Package Clubsport (incl. wiring har‐
ness with motorsport connectors, wheel
speed sensors with serial connectors)
1MBaud:
F 02U V01 289‐49 (DF11S)
F 02U V00 543‐13 (DF11i)
500 kBaud:
F 02U V01 289‐48 (DF11S)
F 02U V00 543‐12 (DF11i)
3 | Technical Data
10 / 54 ABS M4 Manual Bosch Motorsport
