Parts Overview Kit Clubsport
There are a few variants of the ABS M4 Kit Clubsport available:
Description Part Number
ABS M4 Kit Clubsport (1 MBaud, DF11S) F 02U V01 289‐49
ABS M4 Kit Clubsport (500 kBaud,
DF11S)
F 02U V01 289‐48
ABS M4 Kit Clubsport (1 MBaud, for
DF11i)
F 02U V00 543‐13
ABS M4 Kit Clubsport (500 kBaud, for
DF11i)
F 02U V00 543‐12
ABS M4 Kit includes all parts from Kit 1, but a different wiring harness, which
cannot be modified. By default the wiring harness includes a 60 Ohm terminal re‐
sistance, which can be replaced customer specific by a 120 Ohm or deleted com‐
pletely, see wiring diagram ABS M4 Clubsport.
Description Part Number
Wiring harness Clubsport F 02U V01 917‐01
See also
2 Wiring Diagram ABS M4 Clubsport [} 49]
Connectors Overview Kit 1
ABS M4 Kit 1 with part number F 02U V00 289‐01 includes the following connec‐
tors, which are also available as individual spare parts:
Connector for Part Number
Attached control unit connector Standard
wire departure on top: F 02U B00
238‐01
wire departure on top 90°: F 02U B00
238‐01
Alternativ
wire departure on bottom: F 02U B00
237‐01
wire departure on bottom 90°: F 02U
B00 237‐01
Brake pressure sensor
Compact 3‐pin connector
D 261 205 335‐01
12‐positon ABS map switch
ASL 006‐05SE‐HE
F 02U 000 230‐01
ABS warning light (MIL)
ASL 006‐05SA‐HE
F 02U 000 226‐01
5.3
5.4
5 | Included in the Kit
14 / 54 ABS M4 Manual Bosch Motorsport
