Included in the Kit
The following chapter introduces the contents of the different kits.
Parts Overview Kit 1
ABS M4 Kit 1 with part number F 02U V00 289‐01 always includes a wiring har‐
ness. ABS M4 Kit 1 includes the following parts, which are also available as indi‐
vidual spare parts (Hydraulic power unit only in exchange):
Description Part Number
Hydraulic unit with attached ECU Standard (for DF11S wheel speed sen‐
sors): F 02U V00 866‐01
Alternativ (for DF11i wheel speed sen‐
sors): F 02U 002 487‐01
Mounting plate for hydraulic unit with
attached ECU
0 265 Y44 520‐01
Brake pressure sensor 0 261 B08 072‐08
4 wheel speed sensors DF11 0 265 008 022
0 285 007 871 (old model)
Yaw/acceleration sensor Standard 1 MBaud/s: 0 265 005 838
Alternative 500 kBaud/s:
F 02U V00 049‐02
Damping plate for yaw/acceleration
sensor
1 271 032 390
12‐position ABS map switch F 02U V00 111‐03
ABS warning light (MIL) with electronic
control module
Bulb: F 02U V00 112‐01
LED: F 02U V00 112‐02
Incl. wiring harness with motorsport
connectors, customer‐specific layout,
wheel speed sensors with production‐
type connectors.
Similar to connection diagram
F 02U S00 043‐09, see Wiring Diagram
[} 48]
Parts Overview Kit 2
ABS M4 Kit 2 includes all the parts from Kit 1, with the exception of a different
wiring harness with motorsport connectors for the wheel speed sensors.
5
5.1
5.2
Included in the Kit | 5
Bosch Motorsport ABS M4 Manual 13 / 54
