Bosch ABS M4 - Connectors Overview Kit 2; Connectors Overview Kit Clubsport

Connector for Part Number
Wheel speed sensor
Tyco 2‐pin connector
F 02U B00 241‐01
Yaw/acceleration sensor
Tyco 4‐pin connector
F 02U B00 435‐01
Diagnosis connector K‐line F 02U 000 258‐01
Wheel speed signal splitter ABS‐sided
AS 612‐35 SN
F 02U 000 443‐01
Jumper connector for wiring harness
without wheel speed module
AS 112‐35 PN
F 02U 000 304‐01
or
F 02U B00 354‐01
Data‐logger intersection
ASL 006‐05SD HE
F 02U 000 229‐01
Mating connector overview ABS M4‐Paket 1
Connector for Part Number
Brake pressure sensor D 261 205 335‐01
12‐position ABS map switch F 02U 000 230‐01
ABS warning light (MIL) F 02U 000 226‐01
Wheel speed sensor F 02U B00 241‐01
Yaw/acceleration sensor F 02U B00 435‐01
Connectors Overview Kit 2
ABS M4 Kit 2 with part number F 02U V00 290‐01 includes a harness with all the
connectors from Kit 1, with the exception of different connectors for the wheel
speed sensors:
Connector for Part Number
Wiring harness sided
ASL 006‐05PN‐HE
F 02U 000 342‐01
Sensor sided
ASL 606‐05SN‐HE
F 02U 000 416‐01
Connectors Overview Kit Clubsport
ABS M4‐Kit Clubsport with part numbers F 02U V01 289‐49, F 02U V01 289‐48, F
02U V00 543‐13 or F 02U V00 543‐12 includes all connectors of Kit 1, but differ‐
ently the encoding connector:
Connector for Part Number
Encoding connector CAN harness‐side
Super Seal 2‐pole
F 02U B00 246‐01
Encoding connector CAN with a 60 Ohm
resistor
Super Seal 2‐pole
F 02U B00 247‐01
5.5
5.6
Included in the Kit | 5
Bosch Motorsport ABS M4 Manual 15 / 54
