Colors of the status indicator
The status indicator can shine in the following colors:
Red No connection
Yellow Connection in progress
or
MSA Box II cannot create a connection with the ABS (e.g. ABS
switched off)
Green Connection successful, Online mode
White Offline mode
Change between Online and Offline Mode
If a connection does not exist, it is easier to operate with the diagnosis software
in offline mode. Please click with the right mouse button on the green status in‐
dicator to choose between online and offline mode:
A green status indicator signalizes the online mode; a white status indicator sig‐
nalizes the offline mode.
9 | Programming and Diagnosis Software
26 / 54 ABS M4 Manual Bosch Motorsport
