Bosch C 60 - Connector Pin Assignments

Inputs and Outputs
5.6 Pin Layout Life Connector
Life Connector ASDD-2-12-41PN (Red)
Pin
Name
Description
Direction
Remark
1
UBATT
power supply Ubat
input
2
switched positive Kl.15
switched power supply Ubat
input
3
switched positive Kl.15
switched power supply Ubat
input
4
unit ground
ground power supply
input
5
unit ground
ground power supply
input
6
7
8
9
ETH1_TX+
ETH1_TX
-
ETH1_RX+
ETH1_RX-
Ethernet interface 1 (10/100BaseT)
bidirecti
onal
dataline
10
ETH_SCR
screen for Ethernet
screen
11
12
13
14
ETH2_TX+
ETH2_TX
-
ETH2_RX+
ETH2_RX-
Ethernet interface 2 (10/1
00BaseT)
bidirecti
onal
dataline
15
16
17
18
ETH3_TX+
ETH3_TX
-
ETH3_RX+
ETH3_RX
-
Ethernet interface 3 (10/100BaseT)
bidirecti
onal
dataline
19
20
CAN1_H
CAN1_L
CAN interface 1 (upto 1 MBit/s)
bidirecti
onal
dataline
MS 3/MS 4 CardMemory
21
22
CAN2_H
CAN2_L
CAN interface 2 (upto 1 MBit/s)
bidirecti
onal
dataline
23
not connected
unused
spare
do not connect
24
not connected
unused
spare
do not connect
25
not connected
unused
spare
do not connect
26
not connected
unused
spare
do not connect
27
SENSPWR5_1
5 V power supply for analog sensors
output
28
SENSGND_1
sensor ground 1
output
29
TimeSync
signal of synchronisat
ion
inout
used for timing of system
components
30
LS_GND_1
PWM ground
output
31
LS_SWITCH_1
PWM lowside switch 1
input
32
LS_SWITCH_2
PWM lowside switch 2
input
33
LS_SWITCH_3
PWM lowside switch 3
input
34
LS_SWITCH_4
PWM lowside switch 4
input
35
LS_GND_2
PWM ground
output
36
ANA01
analog signal 1
input
37
ANA02
analog signal 2
input
38
ANA03
analog signal 3
input
39
ANA04
analog signal 4
input
40
ANA05
analog signal 5
input
