Bosch C 60 - Pin Layout Sensor Connector

Inputs and Outputs
5.7 Pin Layout Sensor Connector
Sensor Connector ASDD-2-12-41PA (Yellow)
Pin
Name
Description
Direction
Remark
1
UBATT_FUSE1
battery voltage supply
output
2
SENSPWR10_1
10 V power supply for analog sensors
output
3
SENSPWR5_2
5 V power supply for analog sensors
output
4
SENSPWR5_3
5 V power supply for analog sensors
output
5
SENSPWR5_4
5 V power supply for analog sensors
output
6
SENSGND_2
sensor ground 2
output
7
SENSGND_3
sensor ground 3
output
8
9
RS232_1_TX
RS232_1_RX
RS232_1 transmit data
RS232_1 receive data
bidirecti
onal
dataline
used for
telemetry link
10
11
RS232_2_TX
RS232_2_RX
RS232_2 transmit data
RS232_2 receive data
bi
directional
dataline
used for GPS
-
sensor
12
RS232_GND
RS232 ground
13
14
REV1_P
REV1_M
speed signal 1 positive (ind. and hall)
speed signal 1 negative (ind.)
input
15
16
REV2_P
REV2_M
speed signal 2 positive (ind. and hall)
speed signal 2 negative (ind.)
input
17
18
REV3_P
REV3_M
speed signal 3 positive (ind. and hall)
speed signal 3 negative (ind.)
input
19
20
REV4_P
REV4_M
speed signal 4 positive (ind. and hall)
speed signal 4 negative (ind.)
input
21
ANA07
analog signal 7
input
22
ANA08
analog signal 8
input
23
ANA09
analog signal 9
input
24
ANA10
analog signal 10
input
25
ANA11
analog signal 11
input
26
ANA12
analog signal 12
input
27
ANA13
analog signal 13
input
28
ANA14
analog signal 14
input
29
ANA15
analog signal 15
input
30
ANA16
analog signal 16
input
31
ANA17
analog signal 17
input
32
ANA18
analog signal 18
input
33
ANA19
analog signal 19
input
34
ANA20
analog signal 20
input
35
ANA21
analog signal 21
input
36
ANA22
analog signal 22
input
37
ANA23
analog signal 23
input
38
ANA24
analog signal 24
input
39
ANA25
analog signal 25
input
40
ANA26
analog signal 26
input
41
LAP_TRIG
laptrigger input
input
