5.3.2 Ethernet Channels
The C 60 has three 100 MBit full duplex Ethernet communication ports. The ports are internally
connected with an Ethernet switch. The ethernet ports have 'cable auto crossover' functionality.
5.3.3 RS232 Ports
The C 60 has two RS232 serial ports. Baudrate for both ports is programmable. RS232 port 1 is
reserved for online telemetry, port 2 can be used for reception of data from a serial GPS receiver.
5.3.4 Vehicle Diagnosis Connector
The Bosch Motorsport vehicle diagnosis connector is used as a standard interface to connect the
vehicle to a PC e.g. via a MSA-Box II. Loom connector: AS 0-12-35SN
Pin
Name
Description
Used for C 60
Pin 1
Terminal 30
Permanent positive
+
Pin 2
Terminal 15
Switched positive
+
Pin 3
Terminal 31
GND
+
Pin 4
CAN High
Diagnostic CAN bus
Pin 16
CAN Low
Diagnostic CAN bus
Pin 10
K-Line
ECU diagnosis
Pin 8
Ethernet RxD +
Ethernet interface
+
Pin 9
Ethernet RxD -
Ethernet interface
+
Pin 11
Ethernet TxD +
Ethernet interface
+
Pin 12
Ethernet TxD -
Ethernet interface
+
Pin 22
Screen
Cable screen
+
