C 60 Recording and Telemetry
Internal | BEG/EMS1 CsM | 6/4/2010 | © Bosch Engineering GmbH 2009. All rights reserved, also regarding any disposal, exploitation,
reproduction, editing, distribution, as well as in the event of applications for industrial property rights.
Motorsport
C 60 Recording and Telemetry
 C 60 features
 Recording
 Synchronized recording of
 C 60 analog and digital input channels
 C 60 internal measurement channels
 ECU data
 Data from external sensor interfaces
 Up to two independent recordings
 Measurement rate 1ms…1s
 Two global start conditions (thresholds)
 Up to 16 measurement conditions (fast-slow-switches)
 Telemetry
 Support for long-range online telemetry
 Individual programmable team code
 Fast block – slow block mechanism
 Programmable data rate
 Burst telemetry
 Support for burst telemetry (BT-60)
 Programmable IP configuration
 BT-60 diagnosis via C 60
