Lap
Trigger System
Internal | BEG/EMS1 CsM
| 6/4/2010 | ©
Bosch Engineering GmbH 2009. All rights reserved, also regarding any disposal, exploitation,
reproduction, editing, distribution, as well as in the event of applications for industrial property rights.
Motorsport
Counting Outings / Laps / Fragments
Lap 1
Outlap
Lap 2 Lap 3 Lap 4 Lap 5 Lap 6
Inlap
Time
Speed
Start of
Recording
End of
Recording
(Power OFF)
Lap trigger Lap trigger Lap trigger Lap trigger Lap trigger
Power
ON
Outing
Functionality
Power ON: system + measurement is initialized but not yet started
Global start condition fulfilled: recording starts
Reception of valid lap trigger: recording of lap completed, new lap starts
Power OFF: recording of lap completed, system shutdown
