CAN Bus Configuration
Internal | BEG/EMS1 CsM | 6/4/2010 | © Bosch Engineering GmbH 2009. All rights reserved, also regarding any disposal, exploitation,
reproduction, editing, distribution, as well as in the event of applications for industrial property rights.
Motorsport
C 60 CAN Input
 Online view of CAN variables in vehicle
 Double click on ‘Sheet 1’ in project tree
 Measurement Sheet 1 is displayed in main area
 Click on ‘CAN Input’ of desired CAN bus to display variables
 Drag and drop desired variable into measurement sheet
 A menu opens
 Select desired display element (e.g. measurement label) for the variable
