The channel is inserted into the C 60 project tree
C 60 Analog and Frequency Inputs
Internal | BEG/EMS1 CsM
| 6/4/2010 | ©
Bosch Engineering GmbH 2009. All rights reserved, also regarding any disposal, exploitation,
reproduction, editing, distribution, as well as in the event of applications for industrial property rights.
Motorsport
Configuring Inputs –
Characteristic Curve
Available measurements for channel:
Channel is
linked to
ANA03
Input pin
Pull-up
resistor is
activated
Characteristic
curve for
sensor
Adjustment
Is disabled
