94
 The second part of the ‘Computed Sensitivity / Offset Wizard’ opens
 Click ‘Finish’ when done
 Enter channel name and description
 Click ‘OK’ when done
C 60 Analog and Frequency Inputs
Internal | BEG/EMS1 CsM | 6/4/2010 | © Bosch Engineering GmbH 2009. All rights reserved, also regarding any disposal, exploitation,
reproduction, editing, distribution, as well as in the event of applications for industrial property rights.
Motorsport
Computed Sources
Enter physical
limits of the
channel here
Choose data
type of the
measurement
variable here
Physical
limits of
channel
This sensor does
not need offset
calibration
